Large Quantity Of Steel Rail-Light Rail And Heavey Rail Manufacture
Light rail is the nominal weight less than or equal to 30 kg per meter of the rail. Light rail, the low proportion of the quality requirements of rail requires only test its chemical composition, tensile strength, hardness and drop test, etc
Mining rail steel
Specification: 6 kg, 9 kg, 12 kg, 15 kg, 22 kg, 30 kg, 8 kg, 18 kg, 24 kg
Material: 55 q/Q235B
Execution standard:, YB222 GB11264-89-89
Length: 6 to 12 m
| GB11264-2012 STANDARD LIGHT RAIL |
| LIGHT RAIL SIZE (Kg/M) | DIMENSION (MM) | Theory Weight (Kgs/M) | MATERIAL |
| HEIGHT | BASE | HEAD | WEB |
| 8 | 65.00 | 54.00 | 25.00 | 7.00 | 8.42 | Q235 |
| 9 | 63.50 | 63.50 | 32.10 | 5.90 | 8.94 | Q235 |
| 12 | 69.85 | 69.85 | 38.10 | 7.54 | 12.2 | Q235/55Q |
| 15 | 79.37 | 79.37 | 42.86 | 8.33 | 15.2 | Q235/55Q |
| 18 | 90.00 | 80.00 | 40.00 | 10.00 | 18.06 | Q235/55Q |
| 22 | 93.66 | 93.66 | 50.80 | 10.72 | 22.30 | Q235/55Q |
| 24 | 107.00 | 92.00 | 51.00 | 10.90 | 24.46 | Q235/55Q |
| 30 | 107.95 | 107.95 | 60.33 | 12.30 | 30.10 | Q235/55Q |
Products information
| THE LIST OF YYGT |
| |
| Name of Commodity | Specificaton | Materials (Steel Grade) | Standard of Products | Theory Weight (kgs/M) | Length of Dimension (M) | Packed In Bundle With Iron Wire (pcs/bundle) |
| Light Rail | 4kgs/m | Q235 | Q/YG001-2014 | 4kgs/m | 6,8 | 75 |
| 8kgs/m | Q235 | Q/YG001-2014 | 8.42kgs/m | 55 |
| 12kgs/m | Q235 | GB11264-2012 | 12.2kgs/m | 36 |
| 15kgs/m | Q235/55Q | GB11264-2012 | 15.2kgs/m | 6,8,9,10 | 28 |
| 18kgs/m | Q235/55Q | Q/YG001-2014 | 18.06kgs/m | 21 |
| 22kgs/m | Q235/55Q | GB11264-2012 | 22.3kgs/m | 21 |
| 24kgs/m | Q235/55Q | Q/YG001-2014 | 24.46kgs/m | 21 |
| 30kgs/m | Q235/55Q | GB11264-2014 | 30.1kgs/m | 15 |
| Heavy Rail | 38kgs/m | U71Mn | GB2585-2007 | 38.733kgs/M | 12,12.5 | 10 |
| 43kg/m | U71Mn | GB2585-2007 | 44.653kgs/M | 10 |
| 50kgs/m | U71Mn | GB2585-2007 | 51.514kgs/M | 10 |
| | 45/50Mn | Q/YYG002-2008 | 31/34/36/39/41kgs/M | 12,12.5 | 10 |
| Crane Rail | QU70 | U71Mn | YB/T5055-93 | 52.8kgs/m | 12 | 10 |
| QU80 | YB/T5055-93 | 63.69kgs/m | 10 |
| QU100 | YB/T5055-93 | 88.96kgs/m | 5 |
| QU120 | YB/T5055-93 | 118.1kgs/m | 5 |
| I-beam of Hot-Rolled Section Steel for Mine | 9# | Q235 | YB/T5047-2000 | 17.69kgs/m | 8,9,10 | 28 |
| 11# | 20MnK/ Q235 | YB/T5047-2000 | 26.05kgs/m | 18 |
| 12# | YB/T5047-2000 | 31.18kgs/m | 15 |
| Hot-Rolled U-Beam Steel for Mine Timbering | 25U | 20MnK/ Q275 | GB4697-2008 | 24.95kgs/m | 8,9,10,12 | 15 |
| 29U | GB4697-2008 | 29kgs/m | 15 |
| 36U | GB4697-2008 | 35.87kgs/m | 15 |
| | | | | | | |
| | | | | | | |
| Name of Commodity | Specification | Materials | Standard of Products | Theory Weight (kg/set) | Length of Dimension (MM) | Packed in Bundle with Iron Wire (SETS) |
| (Steel Grade) |
| Fish Plate | 8kg/m | Q235 | GB11265-89 | 0.80-1.00 | ≈270-385 | 50 |
| 12kg/m | 1.00-1.50 | ≈409 | 50 |
| 15/18kg/m | 1.90-2.80 | ≈372-409 | 25 |
| 22kg/m | 3.30-7.50 | ≈426-510 | 20 |
| 24kg/m | 3.30-9.60 | ≈426-510 | 10 |
| 30kg/m | 6.00-11.00 | ≈561 | 5 |
| 38/43kg/m | GB185-63 | 19.20-29.6 | ≈790 | 1 |
| 50kg/m | 21.2-35.2 | ≈790 | 1 |
Noted:We can produce as client's reqirements
